By Joseph Eggington (Imperial College London)

The Earth's dipole axis is tilted with respect to the Sun; the extent of this tilt, given by the ‘dipole tilt angle’, changes both diurnally and seasonally as the planet orbits and rotates. This introduces numerous variabilities in the coupled magnetosphere‐ionosphere system, such as altering the location and intensity of magnetic reconnection, allowing the tilt angle to strongly influence magnetospheric convection. In this study, we perform global magnetohydrodynamic (MHD) simulations of the steady‐state magnetosphere‐ionosphere system using the Gorgon MHD code. We drive the system with purely southward Interplanetary Magnetic Field (IMF) conditions for tilt angles from 0–90°, exploring hypothetical configurations beyond the actual extreme of ~30° to elucidate the underlying tilt angle dependence of the system. We identify the location of the magnetic separator (the 3-D reconnection X-line) with increasing tilt angle, showing how the shift of the separator southward on the magnetopause and the resulting changes in the reconnection rate lead to weaker and more time-dependent coupling with the solar wind at large tilt angles.

These trends map down to the ionosphere, with the polar cap contracting as the tilt angle increases, and the region I field‐aligned current (FAC) system migrating to higher latitudes with changing morphology. As shown in the Figure, the hinging of the magnetotail current sheet towards the equator in a tilted configuration results in a longer convection pathway for open field lines in the Northern hemisphere, as the reconnection site on the nightside is shifted more weakly than on the dayside. This introduces a North‐South asymmetry in magnetospheric convection, driving more FAC in the Northern ionosphere for large tilt angles than in the South independent of hemispheric differences in conductance. These results highlight the strong sensitivity to onset time in the potential impact of a severe space weather event, since the intensity of stormtime FACs at a given location on the ionosphere will depend closely on the orientation of the dipole axis.

Figure: Animation of the effect of a changing dipole tilt angle on the magnetosphere-ionosphere system. The left panel shows a contour map of the magnetospheric current density in the noon-midnight meridian plane, with magnetic field lines in black. The orange crosses mark the approximate location of the dayside and nightside reconnection sites; the white dashed line shows the magnetopause location, and the solid white line represents the magnetic equator. The two right panels show contours of the FAC in the northern and southern ionosphere, with the open-closed boundary as a black dotted line.

Please see the paper for full details:

Eggington, J. W. B., Eastwood, J. P., Mejnertsen, L., Desai, R. T., & Chittenden, J. P. (2020). Dipole tilt effect on magnetopause reconnection and the steady‐state magnetosphere‐ionosphere system: Global MHD simulations. Journal of Geophysical Research: Space Physics, 125, e2019JA027510. https://doi.org/10.1029/2019JA027510

By Mayur Bakrania (Mullard Space Science Laboratory, UCL)

Solar wind electron velocity distributions at 1 au consist of a thermal 'core' population and two suprathermal populations: 'halo' and 'strahl'. The core and halo are quasi-isotropic, whereas the strahl typically travels along the parallel and/or anti-parallel direction with respect to the interplanetary magnetic field. The energies at which the halo and strahl populations are separated from the core population are known as the breakpoint energies, and these energies provide useful information on the relative importance of scattering mechanisms.

With Cluster-PEACE data, we analyse energy and pitch angle distributions and use machine learning techniques to separate and classify these solar wind populations. In our statistical study, we apply the K-means algorithm to phase space density distributions over ten years to study the variation of halo and strahl breakpoint energies with solar wind parameters. Key findings include:

• Halo and strahl suprathermal breakpoint energies increase with core temperature, with the halo exhibiting a more positive gradient than the strahl, as shown in the Figure. We conclude low energy strahl electrons are scattering into the core, instead of the halo. This increases the number of Coulomb collisions and extends the perpendicular core population to higher energies, resulting in a larger difference between halo and strahl breakpoint energies at higher core temperatures.
• Suprathermal breakpoint energies decrease with increasing solar wind speed. We also observe distinct profiles for fast and slow solar wind and conclude the origin of the solar wind, i.e., coronal holes for fast wind or streamer belt regions for slow wind, potentially plays a role in the definition of thermal and non-thermal electron populations.

This extensive and novel study reveals key characteristics of the solar wind electron populations. The results provide crucial information on the generation of solar wind electron populations as the solar wind propagates through the heliosphere.

Figure. (Top) `Violin plot' of halo breakpoint energy against core temperature. The blue line shows the line of best fit. The white dots indicate the median of breakpoint energies and the thick black lines show the inter-quartile ranges (IQR). We plot the thin black lines to display which breakpoint energies are outliers. They span from Q3+1.5 X IQR to Q1-1.5 X IQR, where Q3 and Q1 are the upper and lower quartiles, respectively. The horizontal width of the red regions represents the density of data points at that given breakpoint energy. (Bottom) `Violin plot' of strahl breakpoint energy against core temperature. The orange line shows the line of best fit.

Please see the paper for full details:

Bakrania, M. R., Rae, I. J., Walsh, A. P., Verscharen, D., Smith, A. W., Bloch, T. & Watt, C. E. J. (2020). Statistics of solar wind electron breakpoint energies using machine learning techniques, A&A, 639, A46, https://doi.org/10.1051/0004-6361/202037840

by Georgios Nicolaou (Mullard Space Science Laboratory, UCL)

In-situ plasma instruments are often designed to provide the measurements we need to construct the three dimensional velocity distribution functions of plasma species. The proper analysis of the constructed velocity distribution functions derives the bulk properties of the plasma species which are essential in the investigation of the physical mechanisms in plasmas. Although state-of –the-art instruments provide high quality measurements, it is impossible to completely overcome the statistical error related to the counting statistics. The counting error introduces an error to the derived parameters, which is important to quantify in order to define the significance level of the scientific results. The authors simplify the formulas that estimate the statistical error of the plasma parameters which are derived as the statistical moments of observed distribution functions. The simplicity of these expressions allow fast on-board and on-ground calculations. The authors verify the accuracy of the simplistic expressions using numerical simulations of solar wind plasma particles with their velocities following kappa distribution functions. Moreover, the authors explore and quantify the expected error as a function of the distribution function properties.

Figure 1. Normalized standard deviations of the derived (upper left) plasma density, (upper right) bulk speed, (lower left) temperature, and (lower right) kappa index as functions of the maximum counts C_exp, and for VDFs with the same density, speed and temperature, but four different input kappa indices; (black) κ = 2, (orange) κ = 2.5, (blue) κ = 4, and (red) κ = 8. Each data-point is the standard deviation of 1000 values determined from the moments of distribution functions constructed from simulated data.

For more information please see:

Nicolaou, G. & Livadiotis, G. (2020). Statistical Uncertainties of Space Plasma Properties Described by Kappa Distributions. Entropy, 22, 541. https://www.mdpi.com/1099-4300/22/5/541

The full paper can be found at: https://www.mdpi.com/1099-4300/22/5/541

By Sandra Chapman (University of Warwick)

The daily sunspot number record available since 1818 is used to map solar activity over 18 solar cycles to a standardised 11 year cycle or ‘clock’. No two solar cycles are the same, but using the Hilbert transform we are able to standardise the solar activity cycle. The clock reveals that the transitions between quiet and active periods in solar activity are sharp. Once the clock is constructed from sunspot observations it can be used to order observations of solar activity and space weather. These include occurrence of solar flares seen in X-ray by the GOES satellites and F10.7 solar radio flux that tracks solar coronal activity. These are all drivers of space weather on the Earth, for which the longest record is the aa index based on magnetic field measurements going back over 150 years. All these observations show the same sharp switch on and switch off times of activity. Once past switch on/off times are obtained from the clock, the occurrence rate of extreme events when the sun is active or quiet can be calculated, and we find only 1-3% of extreme space storms over the last 150 years occurred in the quiet period of the solar cycle clock.

Figure: Multiple cycles of the irregular, but roughly 11 year cycle of solar and geomagnetic activity is mapped onto a regular solar cycle clock with increasing time read clockwise. Circles indicate the cycle maxima (red), minima (green) and terminators (blue). Measures of solar activity are the daily F10.7 solar radio flux (blue), and GOES X-class, M-Class and C-class solar flare occurrence plotted (red, blue and green scaled histograms). Extreme space weather events at earth seen in the aa geomagnetic index are shown as black dots arranged on concentric circles where increasing radius indicates aa values which in any given day exceeded 100, 200, 300, 400, 500, 600nT, large events appear as ‘spokes’. The clock identified when activity switches on at the terminator and switches off at the pre-terminator (blue lines).

For more information please see:

Chapman S. C., McIntosh, S. W., Leamon, R. J., & Watkins, N. W. (2020). Quantifying the solar cycle modulation of extreme space weather. Geophysical Research Letters, 47, e2020GL087795. https://doi.org/10.1029/2020GL087795
